| Dimensions: | 2250*1400*1640mm |
| Maximum speed: | 45km/h |
| Economic speed: | 35km/h |
| Grand ability: | 12º (20%) |
| Wheelbase: | 1560mm |
| Trackbase: | 1106/1126mm(front),1146mm/1166mm(rear) |
| Rated passenger number: | 2 persons (including driver) |
| Curbweight: | 663kg |
| Weight without battery: | 450kg |
| Min.ground clearance: | 134mm |
| Tire size(mm): | 1/65 R12 |
| Transmission system: | CVT |
| Motor contral system: | 48V/4kw AC motor |
| Charge(input v/kw): | single AC charging |
| Charging time: | 8-10h |
| Batteries:Free maintenance Acid-lead battery | 8v/150Ah*6pieces |
| Max.cruising range: | 100-120km under speed 35km/h |
| Range: | 86KM (at 50 km/h) |
